RVs
- Commodity name： RVs
- Product Description
-
Sichuan Karuitong RV "V362 Roof" Model Configuration Table (2024) model
central axis low roof (ascending)/country VI
diesel
gasoline
basic parameters
vehicle model
ARL5040XLJ
ARL5040XLJ
displacement (L).
1.998
1.997
maximum power (kw).
105
162
maximum torque (N·M/rpm).
305/1400-3200
300/2000-3500
fuel tank volume (L)|100 metric fuel consumption
(90km/h constant speed standard state).
80；7.6
80；11
curb weight|gross mass (kg).
2860；3510
2860；3300
minimum ground clearance (mm)|tire
187；215/75R16 LT
170；215/65R16C
dual generators
12V+12V: dual 150A-2KW
-
gearbox
a 9-speed automatic transmission
number of axes|wheelbase
2；3300mm
body dimensions (length, width & height).
5341/5600mm×2040mm×2175/2190mm
body color
Black■ White□ Color (optional).
standard chassis configuration
Power rearview mirror/Heated mirror/Driver's seat airbag/Reversing camera+Reversing radar/ESP+HHC/cruise control/Automatic headlights/Tire pressure monitoring system/Automatic parking/Telematics configuration package 1*/3.5-inch LCD instrument + 8-inch standard central display
S
high-spec chassis configuration
Electronic Power Steering / Toureo Front Protector / Aluminum Alloy Wheels / Passenger Airbag / Adaptive Headlamp / ADAS Package 1 / Front Automatic Air Conditioning / Keyless Entry (One-button Start) / Connected Car Package 2 * / Dual 12.3-inch LCD integrated screen
□
vehicle modification configuration
> exclusive for the top model
composite reinforcement roof of the monolithic frame structure
S
entertainment
JBL speaker
S
awning rails (water guide + outdoor extension).
S
projector + dedicated folding bracket + projection screen
□
double bed (2000*1310mm) + mattress
S
driver safety assistance
reversing image
S
body and accessories
Extended awning (2.5 m manual).
S
choose one of four channels of monitoring/streaming
□
chassis weld-free installation process
S
electrical system
48V 10 kWh
S
vehicle balance and lightweight design
S
standard harness set
S
recessed outdoor lighting
S
mains charging port + outdoor power port
S
body decal
S
10m charging cable
S
integrated side window is hidden in the passenger compartment*3
S
vehicle charging management
S
heating and cooling air conditioning system
cab driving heating and air conditioning
S
solar charge management system (680W).
□
48V refrigerated row parking air conditioner
S
7-inch touchscreen
S
the supply of warm air for the parking car
S
mobile phone app control system + intelligent voice control system
□
interior
sound insulation, heat insulation, noise reduction, and thermal insulation treatment
S
top modeling light
S
3000W charger and inverter all-in-one machine
S
ambient lighting in the living area (brightness 10 levels adjustment).
S
wireless charging of the phone
S
side panels are one-piece interior parts
S
220V socket + USB socket
S
upholstery on the top and sides of the living area
S
bathroom amenities
separate toilet (screen-type waterproof partition).
S
waterproof and moisture-proof environmental protection floor leather
S
Seidford flush toilets
S
cab partition curtain
S
mirror headlamp + vanity mirror
S
the left and right sides of the living area and the tailgate curtains
S
towel rack
S
the main and co-pilot seats are manually adjusted by a single person
S
recessed folding basin
S
co-pilot rotation function
S
pull-out showerhead
S
quick-release mobile table
S
sojourn model (with kitchen).
kitchen equipment
85L double-door refrigerator + combination cabinet
S
leather upholstery of the vehicle's seats
S
clamshell sink
insect curtain for the middle door
S
induction cooker
waterway system
clean water tank (90L) + sewage tank (50L).
S
4 seats
second row of double folding seats
choose one of 4 seats/6 seats
S
water inlet (gravity water refill + municipal water pass-through + water outlet + 12V cigarette lighter).
S
single bed at the tail (1850*830mm) + mattress
pump + pump filter
S
6 seats
second row of double folding seats
□
hot and cold water supply (food-grade antifreeze quick circuit).
S
third row of double seats (pull-sided).
on-the-go hot water supply system (engine).
S
business traveler with kitchen
electrical equipment
66L double-door refrigerator (12V).
S
parking hot water supply system (fuel heater).
S
4 seats
second row single airline seats*2
choose one of 4 seats/6 seats
S
tank circulating heating system (40 degrees).
S
single bed at the tail (1850*830mm) + mattress
hot and cold water vehicle exhaust system
S
6 seats
second row single airline seats*2
□
clean water and water pipe (10 meters).
S
third row of double seats (pull-sided).
"S" is standard, and "□" is optional
* IoV Configuration Package 1 includes: Vehicle Positioning GPS + Vehicle Self-Test/Early Warning Function + Remote Locking/Unlocking + Vehicle Positioning + Vehicle Status Inquiry + WIFI Hotspot + Security and Early Warning + FOTA Firmware Cloud Upgrade
* Connected Car Package 2 includes: Connected Car Package 1 + 9-speed automatic transmission + keyless entry/one-button start PEPS + remote climate control + remote engine start
* ADAS configuration package 1 includes: driver fatigue detection DMS + blind spot detection BSD + reverse warning system RCTA + door opening warning DOA
* ADAS Package 2 includes: ADAS Package 1 + 9-speed automatic transmission + Traffic jam assist TJA + Adaptive cruise control ACC + automatic emergency braking AEB + Forward Collision Warning FCW + Lane Keeping Assist LKA + Traffic Sign Recognition TSR + Intelligent High Beam Control IHC + Lane Departure Warning LDW
*In view of the fact that Sichuan Karuitong Technology Co., Ltd. will continue to improve and upgrade the product, the above information may be inconsistent with the actual situation, please call the VIP sales service hotline for details: 023-81927038; 15002394449
*The copyright of this document belongs to Sichuan Karuitong Technology Co., Ltd., and reserves the right to pursue the damage caused by this.
*Driver assistance functions are limited to assisting the driver in driving operations, and the driver is solely responsible for judging the road conditions when the function is turned on. The driver must comply with the implementation regulations of China's road traffic safety law, as well as the provisions of applicable laws and regulations such as the application and use of motor vehicle driving licenses, and use the premise of using the function carefully, and take full responsibility for driving the vehicle in accordance with the law. In the event of a violation, accident, or dispute during driving, the driver shall bear full responsibility, and the vehicle itself (as well as the manufacturer and dealer) shall not bear any responsibility.
